32 Inch 2500 Nits High Brightness Touch LCD Module with 3+3 Laminated Glass
Model:XT32IEHWM9661
Product Overview
This 32 inch high brightness touch LCD module is designed for customized outdoor and semi-outdoor display projects. It features 2500 nits brightness, touch film, Android 13 system board, automatic brightness adjustment and 3+3 laminated glass for improved safety and front protection.
The module structure can be customized according to the customer’s project requirements, making it suitable for outdoor kiosks, wall-mounted displays, interactive advertising screens, wayfinding systems and other commercial display solutions.
Product Features
2500 Nits High Brightness Outdoor LCD Screen
The 55 inch LCD screen delivers 2500 nits brightness, making advertising content clearly visible in bright outdoor environments. It is suitable for storefronts, transportation areas, commercial buildings, and public information display.
Front Service Door for Easy Maintenance
The display is designed with a front-access service door, allowing internal components to be maintained or replaced from the front. This helps reduce installation restrictions, service time, and labor cost.
Anti-Theft Lock Design
The front door can be equipped with an anti-theft lock system to prevent unauthorized access to internal components. This makes the display more suitable for public outdoor installation environments such as stations, streets, and commercial plazas.
IP65 Outdoor Protection
The outdoor enclosure is designed for IP65 protection, helping protect the display from rain, dust, and outdoor particles. It is suitable for full outdoor use.
6mm Tempered Safety Glass
The display area is protected by 6mm tempered glass. AG glass is available as an option to reduce reflection and improve readability in bright environments.
Smart Cooling System
The built-in cooling system helps manage internal temperature and supports stable operation in outdoor environments. It is designed for continuous commercial use.
Auto Brightness Control
A built-in light sensor automatically adjusts screen brightness according to ambient light conditions. This improves visibility during daytime and reduces unnecessary power consumption in low-light environments.
Filter-Free Maintenance Design
The design helps reduce regular filter replacement requirements, lowering long-term maintenance workload and improving service efficiency.
Product Specifications
Display Panel
Screen Size: 32 inch
Resolution: 1920 × 1080
Active Area: 396.85 × 702.4 mm
Brightness: 2500 nits
Contrast Ratio: 1200:1
Viewing Angle: 178°
Response Time: 8 ms
Backlight Life: 50,000 hours
Orientation: Landscape / Portrait
Physical
Housing Material: Aluminum+Galvanized
Product Dimensions: 538 × 838 × 101 mm
Net Weight: 15 kg
Packing: Carton or Wooden Case (Optional)
Laminated Tempered Glass: 3+3mm
Environment
Working Environment: Indoor / Window Facing Applications
Operating Temperature: -20°C to 50°C
Operating Humidity: 5%–95%
Continuous Operation: 24/7
Connectivity
HDMI
USB
Optional Extended Interfaces
Power
Input Voltage: AC 100–240V, 50/60Hz
Power Consumption: 95W
System Options
Android 13.0
